REDUCING TEE
NAME: REDUCING TEE
MATERIAL:A234-WPB.A420-WPL6.A234-WP12.A234-WP11.A234-WP5.A403-WP304.A403-WP304L.A403-WP316.A403-WP316L.
SIZE:1/2"-48"?DN15-DN1200
PRESSURE: Sch5-Sch160?XXS
STANDARDS: ISO. ANSI. JIS. DIN GB/T12459?GB/T13401?ASME B16.9?SH3408 SH3409?HG/T21635?HG/T21631?SY/T0501
USE: Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc.
|
Nominal pipe size |
|
|
||||
|
D1 |
D2 |
C |
M |
|||
|
|
|
|
|
|||
|
20×15
|
26.9
|
25
|
21.3
|
18
|
29
|
29
|
|
25×20
25×15 |
33.7
33.7 |
32
32 |
26.9
21.3 |
25
18 |
38
38 |
38
38 |
|
32×25
32×20 32×15 |
42.4
42.4 42.4 |
38
38 38 |
33.7
26.9 21.3 |
32
25 18 |
48
48 48 |
48
48 48 |
|
40×32
40×25 40×20 40×15 |
48.3
48.3 48.3 48.3 |
45
45 45 45 |
42.4
33.7 26.7 21.3 |
38
32 25 18 |
57
57 57 57 |
57
57 57 57 |
|
50×40
50×32 50×25 50×20 |
60.3
60.3 60.3 60.3 |
57
57 57 57 |
48.3
42.4 33.7 26.9 |
45
38 32 25 |
64
64 64 64 |
60
57 51 44 |
|
65×50
65×40 65×32 65×25 |
76.1(73)
76.1(73) 76.1(73) 76.1(73) |
76
76 76 76 |
60.3
48.3 42.4 33.7 |
57
45 38 32 |
76
76 76 76 |
70
67 64 57 |
|
80×65
80×50 80×40 80×32 |
88.9
88.9 88.9 88.9 |
89
89 89 89 |
76.1(73)
60.3 48.3 42.4 |
76
57 45 38 |
86
86 86 86 |
83
76 73 70 |
|
90×80
90×65 90×50 90×40 |
101.6
101.6 101.6 101.6 |
-
- - - |
88.9
76.1(73) 60.3 48.3 |
-
- - - |
95
95 95 95 |
92
89 83 79 |
|
100×90
100×80 100×65 100×50 100×40 |
114.3
114.3 114.3 114.3 114.3 |
-
108 108 108 108 |
101.6
88.9 76.1(73) 60.3 48.3 |
-
89 76 57 45 |
105
105 105 105 105 |
102
98 95 89 86 |
|
125×100
125×90 125×80 125×65 125×50 |
139.7
139.7 139.7 139.7 |
133
- 133 133 133 |
114.3
101.6 88.9 76.1(73) 60.3 |
108
- 89 76 57 |
124
124 124 124 124 |
117
114 111 108 105 |
|
150×125
150×100 150×90 150×80 150×65 |
168.3
168.3 168.3 168.3 168.3 |
159
159 - 159 159 |
139.7
114.3 101.6 88.9 76.1(73) |
133
108 - 89 76 |
143
143 143 143 143 |
137
130 127 124 121 |
|
200×150
200×125 200×100 200×90 |
219.1
219.1 219.1 219.1 |
219
219 219 - |
168.3
139.7 114.3 101.6 |
159
133 108 - |
178
178 178 178 |
168
162 156 152 |
|
200×200
200×150 200×125 200×100 |
273.0
273.0 273.0 273.0 |
273
273 273 273 |
219.1
168.3 139.7 114.3 |
219
159 133 108 |
216
216 216 216 |
208
194 191 184 |
|
300×250
300×200 300×150 |
323.9
323.9 323.9 |
325
325 325 |
273.0
219.1 168.3 |
273
219 159 |
254
254 254 |
241
229 219 |
|
300×125
|
323.9
|
325
|
139.7
|
133
|
254
|
216
|
|
350×300
350×250 350×200 350×150 |
355.6
355.6 355.6 355.6 |
377
377 377 377 |
323.9
273.0 219.1 168.3 |
325
273 219 159 |
279
279 279 279 |
270
257 248 238 |
|
400×350
400×300 400×250 400×200 400×150 |
406.4
406.4 406.4 406.4 406.4 |
426
426 426 426 426 |
355.6
323.9 273.0 219.1 168.3 |
377
325 273 219 159 |
305
305 305 305 305 |
305
295 283 273 264 |
|
450×400
450×350 450×300 450×250 450×200 |
457.2
457.2 457.2 457.2 457.2 |
478
478 478 478 478 |
406.4
355.6 323.9 273.0 219.1 |
426
377 325 273 219 |
343
343 343 343 343 |
330
330 321 308 298 |
|
500×450
500×100 500×350 500×300 500×250 500×200 |
508.0
508.0 508.0 508.0 508.0 508.0 |
529
529 529 529 529 529 |
457.2
406.4 355.6 323.9 273.0 219.1 |
478
426 377 325 273 219 |
381
381 381 381 381 381 |
368
356 356 346 333 324 |
|
550×500
550×450 550×400 |
559
559 559 |
-
- - |
508
457 406 |
-
- - |
419
419 419 |
406
394 381 |
|
600×550
600×550 600×450 |
610
610 610 |
-
630 630 |
559
508 457 |
-
530 480 |
432
432 432 |
432
432 419 |
|
650×600
650×550 650×500 |
660
660 660 |
-
- - |
610
559 508 |
-
- - |
495
495 495 |
483
470 457 |
|
700×650
700×600 700×550
|
711
711 711
|
-
720 -
|
660
610 559
|
-
630 -
|
521
521 521
|
521
508 495
|
|
750×700
750×650 750×600 |
762
762 762 |
-
- - |
711
660 610 |
-
- - |
559
559 559 |
546
546 533 |
|
800×750
800×700 800×650 |
813
813 813 |
-
820 - |
762
711 660 |
-
720 - |
597
597 597 |
584
572 572 |
|
850×800
850×750 850×700 |
864
864 864 |
-
- - |
813
762 711 |
-
- - |
635
635 635 |
622
610 597 |
|
900×850
900×800 900×750 |
914
914 914 |
-
920 - |
864
813 762 |
-
820 - |
673
673 673 |
660
648 635 |
|
950×900
950×850 950×800 |
965
965 965 |
-
- - |
914
864 813 |
-
- - |
711
711 711 |
711
698 686 |
|
1000×950
1000×900 1000×8500 |
1016
1016 1016 |
-
1020 - |
965
914 864 |
-
920 - |
749
749 749 |
749
737 724 |
|
1000×1000
1050×950 1050×900 |
1067
1067 1067 |
-
- - |
1016
965 914 |
-
- - |
762
762 762 |
711
711 711 |
|
1100×1050
1100×1000 1100×950 |
1118
1118 1118 |
-
1120 - |
1067
1016 965 |
-
1020 - |
813
813 813 |
762
749 737 |
|
1150×1100
1150×1050 1150×1000 |
1168
1168 1168 |
-
- - |
1118
1067 1016 |
-
- - |
851
851 851 |
800
787 775 |
|
1200×1150
1200×1100 1200×1050 |
1220
1220 1220 |
-
1220 - |
1168
1118 1067 |
-
1120 - |
889
889 889 |
838
838 813 |
